NO, NO2, NOX Analyzer (Ei400)

High performance nitrogen oxides analyzer with the latest CLD technology

gas dortmund logo.png

Using the proven Chemiluminescence (CLD) measurement principle combined with the latest detector technology, the Ei400 NO/NO2/NOx Analyzer measures the reaction between nitric oxide and ozone to determine the nitric oxide concentration in gas.


Incorporating a blue light LED or thermal converter into the sample path converts nitrogen dioxide into nitric oxide, thus allowing for the measurement of total nitrogen oxides (NOx) concentration.

Features

  • Wide dynamic measurement range (multiple orders of magnitude)

  • Extremely selective and long-lasting blue LED converter eliminates ammonia bias

  • Solid-state detector

  • Sample extraction via educator eliminates need for vacuum pump

  • 7” (or 10” optional) color touchscreen display

  • Auto high-frequency zero correction eliminates drift

  • High sensitivity

  • Automatic calibration

  • Low number of wear items for improved reliability

  • Adaptive signal filtration allows for low noise while maintaining fast response time

  • Automatic temperature and pressure compensation

  • Modbus TCP/IP communication and analog outputs (0-10V or 4-20mA)

  • Remote access capabilities

  • Front panel USB for firmware upgrades, data download, or peripheral devices

  • Innovative InteliSense™ software platform across all Ei analyzers for consistent, simple, and user-friendly interface, operability, and data display

  • InteliSense Software Features:

            -Modern, user-friendly interface

            -Simple set-up and operation

            -Selectable units (ppm, mg/m3, or %)

            -Customizable graphical data display

            -Instrument Alarms

            -Data logging

            -Error logging

            -Zero and span logging

            -“Dark Mode” option

Available Options

  • Thermal Converter

  • External Vacuum Pump

  • 10” Display

  • Enclosure Options:

            -19” Rack-Mount Enclosure

            -Tabletop Enclosure

            -Wall-Mount Enclosure

            -Portable Enclosure

  • Ammonia Measurement Function (only available in presence of low NOx concentration)

  • Add-On Gas Measurements:

            -O2, H2O, CO, CO2, SO2, CH4, H2S, others

Technical Specifications
Persee Technical Specs.jpg
Related Products
Persee Technical Specs.jpg
Typical Applications

  • Continuous Emissions Monitoring (CEMS)

  • Process Monitoring

  • Fuel Cell Analysis

  • Engine Testing

  • Air Quality and Industrial Hygiene

  • Safety

  • Vehicle Emissions

  • Combustion Efficiency

  • Others

Available Configurations

19" Rack

rack design.png

Wall Mount

rack design.png

Tabletop

rack design.png

Portable

rack design.png
Downloads
PDF DL 3.png

Ei400 NO, NO2, NOx Analyzer Flyer

PDF DL 3.png

Application Questionnaire
